Epilog Marking and Cutting systems

Inquire
Manufactured by:
Epilog
Model number:
Marking and Cutting systems
Year manufactured:
2022
Condition:
Very good condition
Asking price:
$27,500
Price when new:
$37,000
Included extras:
 Manual
 Warranty
 Demonstratable
 Training
 Installation
Parts and accessories:
1.5″ Optional Lens 2.0 “Optional Standard Backup Lens 4.0″ Optional Lens Air Assist Pump - Compressor Rim-Style Rotary Attachment Task Plate Engraving Table Slat Table Vector Grid Cutting Table ExpandX FiltraBox – Fume Extractor Expandx FiltraBox set of new replacement filters.
Additional information:
This machine has very low operational hours and is in excellent condition. It provides engraving speeds of up to 165 IPS (4.2 m/s). Maximum Engraving Area: 24” x 24” Max Material Thickness: 9” Standard Features: Radiance High-Definition Optics (CO2), Air Assist, Red Dot Pointer, relocatable Home Position, LED lighting, integrated floor stand, brushless servo motors, Super-Silent Cooling Fans, Joy-stick Controls, removable exhaust plenum Intelligent Memory Buffer: Multiple files up to 1 GB. Operating Modes: Optimized Raster, Vector, and Combined Modes Resolution: Fully flexible and user-controlled from 75 to 1200 DPI Iris Cameras: 2 Overhead + Registration Overall Size: 41.52” x 32.81” x 40.54” Weight: 240 lbs. Electrical Requirements: 120 volts AC, single phase Exhaust Requirements: 350 – 400 CFM external exhaust or filtration system Laser System Classification: Class 2 Laser It has Epilog’s IRIS™ Camera System with Positioning and Registration cutting features, which gives laser operators a live preview of the engraving table so they can quickly and accurately position their artwork on even the most uniquely shaped items. The laser also provides an auto focus function for easy operation and consistent results.
Engraver Type:
Raster and Vector
System Input Power I:
120 VAC
Laser Manufacturer:
Epilog
Laser Model Number:
FusionPro 24
Laser Rated Power (watts):
60 watt
Laser Cooling:
Air
Engraving field size:
24" x 24"
Engraving Software:
CorelDraw
Item Number:
8149
